JET JTM-2 Mill with ACU-RITE 203 DRO and X and Y-Axis Powerfeeds is a precision vertical milling machine engineered by JET for demanding machining applications that require accuracy, durability, and operator control. Built on certified Meehanite castings and equipped with an ACU-RITE 203 digital readout along with X and Y-axis powerfeeds, this step-pulley R-8 mill delivers the rigidity and repeatability that skilled machinists depend on in professional shop environments.

Key Features

• Certified Meehanite castings provide exceptional rigidity and vibration damping for precise milling performance
• Heavy duty splined motor drive ensures reliable, consistent power transmission
• Internal coolant tank built into base for use with coolant system (coolant pump not included)
• Large diameter quill is chromed for durability and smooth travel
• One shot lubrication system simplifies maintenance and extends machine life
• Precision bored and honed milling head for superior spindle accuracy
• Precision hardened and ground ways deliver smooth, accurate axis movement
• Spindle head is internally cooled to prevent seizing during extended operations
• Three stage power downfeed with automatic stop for controlled, repeatable depth cuts
• ACU-RITE 203 Digital Readout (DRO) for accurate, real-time axis position monitoring
• X and Y-axis powerfeeds for consistent, hands-free table movement
• Tolerance test sheet included to verify machine accuracy out of the box
• Backed by the JET Two Year Warranty

Specifications

• MPN: JT9-690210
• Style (Type): Step Pulley R8
• Motor: 2 HP, 115/230V, 1Ph
• Number of Spindle Speeds: 8
• Range of Spindle Speeds (RPM): 80 - 2,720
• Spindle Taper: R-8
• Spindle Travel (In.): 5
• Quill Diameter (In.): 3-3/8
• Quill Down Feed Rates (IPR): .0015 - .003 - .006
• Collet Capacity: 1/8 - 7/8
• Table Size (L x W) (In.): 9 x 42
• Table Longitudinal Travel (In.): 23-7/8
• Table Longitudinal Travel With Powerfeed (In.): 20-2/7
• Table Cross Travel (In.): 12-1/2
• T-Slot Centers (In.): 2-1/2
• Travel of Knee (In.): 14-1/2
• Distance Spindle to Column (Max.) (In.): 19
• Max Distance Spindle to Table (In.): 17-1/2
• Overall Dimensions (L x W x H) (In.): 57 x 64 x 82
• Number of Axis: 2
• Powerfeed: X and Y-Axis
• Prop 65: Cancer and Reproductive Harm
• Country of Origin: Taiwan

What's Included

• JET JTM-2 Vertical Milling Machine
• ACU-RITE 203 Digital Readout (DRO)
• X and Y-Axis Powerfeeds
• Tolerance test sheet

Frequently Asked Questions

What type of spindle taper does the JET JTM-2 use?

The JET JTM-2 uses an R-8 spindle taper, which is a widely used standard in vertical knee mills. The collet capacity ranges from 1/8 to 7/8 inch, providing compatibility with a broad range of tooling.

What are the available quill down feed rates on this mill?

The JTM-2 features three stage power downfeed with automatic stop. The available quill down feed rates are .0015, .003, and .006 inches per revolution (IPR), giving operators control over feed rate to match different materials and tooling requirements.

Is a coolant pump included with this machine?

The JTM-2 includes an internal coolant tank built into the base for use with a coolant system; however, the coolant pump is not included and must be purchased separately.

What digital readout system comes with this mill, and how many axes does it cover?

This mill is equipped with an ACU-RITE 203 Digital Readout (DRO) covering 2 axes, paired with X and Y-axis powerfeeds. This combination provides real-time position feedback and powered table movement for accurate, repeatable machining operations.
