Product Description
The Simpson U310 Face-Mount Joist Hanger is a precision-formed, 16-gauge steel connector engineered for joist-to-header installation in wood-framed construction. Manufactured by Simpson, this face-mount hanger delivers dependable structural performance for floor and roof framing applications where tested strength, straightforward installation, and code compliance are non-negotiable.
Key Features
- Tested, load rated, and code compliant - gives builders and inspectors confidence that the hanger meets recognized structural standards right out of the box.
- Compatible with several fastener selections, each with tested allowable loads - provides installation flexibility so crews can work with the nail sizes they have on hand without sacrificing verified performance.
- Fits nominal 3x10 and 3x12 joist members - covers two common framing dimensions in a single hanger model, reducing the number of SKUs needed on the job site.
- Formed from 16-gauge steel - delivers the structural rigidity required for demanding load-bearing framing connections in residential and light commercial construction.
- G90 zinc galvanized finish - provides extra corrosion resistance, making the hanger suitable for applications where moisture exposure is a concern.
Why This Product
- Engineered for real-world framing conditions - the U-series design is purpose-built for joist-to-header connections, so it fits naturally into standard wood-frame construction workflows without modification or guesswork.
- Dual-size compatibility reduces job site complexity - a single U310 hanger supports both 3x10 and 3x12 nominal lumber, giving framing crews a versatile connector that adapts to changing layout requirements.
- G90 galvanized coating goes beyond basic protection - the extra corrosion resistance extends the service life of the connection in crawl spaces, covered decks, and other environments where bare steel would degrade over time.
- Precision-formed construction from a trusted brand - Simpson manufactures the U310 to high quality standards, and its tested, load-rated performance means structural calculations and code submissions are backed by documented data.
Specifications
- Model Number: U310
- Gauge: 16
- Width (W): 2-9/16 in.
- Height (H): 8-7/8 in.
- Base (B): 2 in.
- Coating/Finish: Zinc Galvanized, G90
- Member Size: 3x10, 3x12
- Installation Fasteners: 10d or 16d common nails in the header and 10d x 1-1/2 in. nails in the joist (sold separately)
- Country of Origin: United States
Options
- Contact us for Configurable Options and Special orders
- Refer to technical bulletin for ease of ordering a Custom U hanger
Load Tables / Values / Installation
- Face-Mount Hangers - Solid Sawn Lumber (DF / SP) Tables
- Face-Mount Hangers - Solid Sawn Lumber (SPF / HF) Tables
- Face-Mount Hangers - Rough Lumber (DF / SP / SPF / HF) Tables
- Face-Mount Hangers - I-Joists, Glulam and SCL Tables
Downloads and Resources
- Face-Mount Hangers - Solid Sawn Lumber (SPF / HF) Tables
- Face-Mount Hangers - Rough Lumber (DF / SP / SPF / HF) Tables
- Face-Mount Hangers - Solid Sawn Lumber (DF / SP) Tables
- Face-Mount Hangers - I-Joists, Glulam and SCL Tables
Note: Product dimensions and/or Nail or Screw holes may differ from picture. Please see item description for specifications.
Frequently Asked Questions
What lumber sizes is the Simpson U310 joist hanger compatible with?
The U310 is designed for nominal 3x10 and 3x12 joist member sizes, making it versatile for common wood-framed floor and roof framing applications.
What fasteners are required to install the U310 joist hanger?
Installation calls for 10d or 16d common nails in the header and 10d x 1-1/2 in. nails in the joist. The U series supports several fastener selections, each with tested allowable loads.
Is the Simpson U310 corrosion resistant?
Yes. The U310 features a G90 zinc galvanized coating, which provides an extra level of corrosion resistance suited for use in demanding construction environments.
Is the Simpson U310 code compliant?
Yes. U-series hangers are tested, load rated, and code compliant, ensuring they meet the structural requirements of wood-framed construction projects.
