The Simpson HU68 Galvanized Face-Mount Joist Hanger by Simpson is a heavy-duty structural connector engineered for nominal 6x8 lumber connections that demand reliable load transfer and lasting durability. Built from 14-gauge steel with a Zinc Galvanized (G90) coating, this face-mount hanger is the go-to choice for engineers and contractors tackling framing applications where additional strength and safety factors are required. The "U" design offers placement flexibility on the header, and tested, load-rated performance ensures the connection meets building code requirements on residential and commercial projects alike.

Key Features

• Extra optional triangle holes for additional load - gives you the ability to increase the load capacity of the connection when project conditions demand it, without switching to a different hanger.
• Tested, load-rated, and code-compliant construction - HU-series hangers carry verified load ratings so contractors and inspectors can confirm code compliance with confidence.
• "U" design allows for flexibility of placement on the header - simplifies installation by letting you position the hanger where it best suits your framing layout rather than working around a fixed profile.
• 14-gauge steel construction - provides the structural rigidity and strength needed for heavy-duty joist connections supporting substantial loads.
• Zinc Galvanized (G90) coating - delivers corrosion resistance that helps the hanger hold up in moisture-exposed framing environments over the long term.
• 5-1/2 in. seat width sized for nominal 6x8 lumber - ensures a secure, properly fitted cradle for the joist member so the connection performs as rated from day one.

Why This Product

• Heavy-duty performance backed by real testing - Simpson HU-series hangers are tested and load-rated, meaning the numbers on the data sheet reflect verified performance rather than estimates, giving engineers and contractors a reliable basis for structural design.
• Built-in flexibility for higher-load applications - the extra optional triangle holes allow installers to add fasteners when a project requires a stronger connection, making this single hanger adaptable to a wider range of loading conditions.
• Corrosion resistance where it matters - the G90 galvanized finish is designed to withstand moisture exposure, making this hanger a practical choice for exterior structures, covered decks, and other framing environments where bare steel would be at risk.
• Engineered and manufactured to consistent quality standards - Simpson connectors are produced to tight manufacturing tolerances, so the fit, fastener hole alignment, and load performance are predictable across every hanger - reducing surprises during installation and inspection.

Specifications

• MPN: HU68
• Member Size: 6x8
• Height: 5-13/16 in.
• Width: 5-1/2 in.
• Seat Depth: 2-1/2 in.
• Gauge: 14
• Coating/Finish: Zinc Galvanized, G90
• Country of Origin: United States
• Installation: Install with (10-14) 0.162 in. x 3-1/2 in. nails in the header and (4-6) 0.162 in. x 3-1/2 in. nails in the joist (sold separately)

Options

• Contact us for Configurable Options and Special orders

Frequently Asked Questions

What size lumber is the HU68 designed to support?

The HU68 is designed for nominal 6x8 lumber, with a seat width of 5-1/2 in. to securely cradle the joist member.

What fasteners are required to install the HU68?

Installation requires (10-14) 0.162 in. x 3-1/2 in. nails in the header and (4-6) 0.162 in. x 3-1/2 in. nails in the joist for a proper, code-compliant connection.

Is the HU68 suitable for outdoor or moisture-exposed applications?

Yes. The HU68 features a Zinc Galvanized (G90) coating, which provides corrosion resistance, making it appropriate for use in environments where moisture exposure is a concern.

Is the HU68 code compliant?

Yes. HU-series hangers are tested, load rated, and code compliant, making them a reliable choice for projects that must meet building code requirements.

Note: Product dimensions and/or fastener holes may differ from picture. Please see item description for specifications.
