Product Features
Product Description
Key Features
- Uniformly Brazed Carbide Inserts: Precision brazing technique results in longer bit life and consistent cutting performance over extended use.
- Centering Tip: Facilitates easy spot drilling for accurate hole placement without wandering.
- Chromium-Nickel-Molybdenum Steel Alloy Body: Ensures superior hammering quality and extended service life under repeated rotary hammer impact.
- Heat-Treatment & Shot-Peened Finish: Increases surface hardness, improves drilling speed, reduces drill bit wear, and enhances resistance to bending forces.
- ANSI Standard B212.15 Compliant: Drill bits conform to ANSI Standard B212.15 for verified dimensional and performance consistency.
- High-Volume, Multi-Flute Spiral: Quickly channels concrete dust away from the hole to maintain drilling speed and reduce clogging.
- 4 x 90 deg. Quad Head Geometry: Crushes through rebar and prevents the bit from sticking in reinforced concrete.
- SDS-Plus Shank: Compatible with SDS-plus rotary hammer tools for secure, tool-free bit changes.
- Made in Germany: Manufactured to the highest industry standards for Simpson Strong-Tie.
Specifications
- Model Number (MPN): MDPL07508Q
- Shank Type: SDS-plus Shank
- Head Type: Quad Head 4x Drill Bit
- Diameter: 3/4 in.
- Overall Length: 8 in.
- Drilling Depth: 6 in.
- Material: Hardened Steel (Chromium-Nickel-Molybdenum Steel Alloy) with Carbide-Tipped Inserts
- Standard Compliance: ANSI Standard B212.15
Frequently Asked Questions
- What type of rotary hammer is this drill bit compatible with?
- This drill bit features an SDS-plus shank, making it compatible with SDS-plus rotary hammer tools. The SDS-plus shank design allows for secure, tool-free bit changes.
- Can this bit drill through reinforced concrete containing rebar?
- Yes. The 4 x 90 deg. Quad Head geometry is specifically designed to crush through rebar and prevent the bit from sticking in reinforced concrete, making it well suited for drilling into reinforced concrete applications.
- What are the key dimensions of this drill bit?
- The bit has a diameter of 3/4 in., an overall length of 8 in., and a maximum drilling depth of 6 in.
- What standards does this drill bit conform to, and what materials is it made from?
- This drill bit conforms to ANSI Standard B212.15 for verified dimensional and performance consistency. The body is constructed from a chromium-nickel-molybdenum steel alloy with uniformly brazed carbide-tipped inserts. A heat-treatment process and shot-peened finish are applied to increase surface hardness, improve drilling speed, reduce wear, and enhance resistance to bending forces.
