Product Features
Product Description
JET JMD-45GH Geared Head Square Column Mill/Drill from JET is a heavy-duty mill/drill engineered to deliver the rigidity and precision required for a wide variety of demanding drilling and milling applications in high-intensity environments. Powered by a 1-1/2HP motor and featuring a 6-speed geared head, this machine provides full power to cutting tools across its full speed range, making it a reliable choice for professionals who need consistent, repeatable results.
Key Features
- Calibrated fine down feed built in for precise depth control
- CSA/CUS Certified for safety and compliance
- Easy to read internal depth gauge for accurate drilling depth monitoring
- Full power to the cutting tools through 6 speed geared head
- Heavy-duty design allows for a variety of precision drilling applications
- Milling table allows for movement to reposition workpieces with ease
- R8 spindle allows use of all mill tooling for maximum versatility
- Rapid spindle speed changes through quick-select gear shift levers
- Square column with dovetail ways for enhanced rigidity and accuracy
- Mill Drill Stand (p/n 350045), shown in some images, is optional and sold separately
Specifications
- Stock Number: 351045
- Motor: 1-1/2HP, 115/230V, 1Ph
- Number of Spindle Speeds: 6
- Range of Spindle Speeds (RPM): 65-1550
- Spindle Taper: R8
- Spindle Travel (In.): 5
- Quill Diameter (In.): 3
- Table Size (L x W) (In.): 9-1/2 x 32-1/4
- Table Longitudinal Travel (In.): 20-1/2
- Max Distance Spindle to Table (In.): 18-1/8
- Face Mill Capacity (In.): 4
- Swing (In.): 19-11/16
- Base Dimensions (In.): 26-11/16 x 15-15/16
- Overall Dimensions (L x W x H) (In.): 29 x 36 x 50
- Weight (Lbs.): 794
- Country of Origin: Taiwan
- Prop 65: Cancer and Reproductive Harm
Frequently Asked Questions
- What type of spindle does the JMD-45GH use, and what tooling is compatible?
- The JMD-45GH features an R8 spindle, which allows use of all mill tooling. This is a widely adopted taper standard, giving operators access to a broad selection of collets, end mill holders, drill chucks, and other accessories.
- How many spindle speeds are available, and how are they changed?
- The machine offers 6 spindle speeds ranging from 65-1550 RPM. Speed changes are made quickly and easily through quick-select gear shift levers, minimizing downtime between operations.
- Does the JMD-45GH include a built-in depth gauge?
- Yes. The machine features an easy to read internal depth gauge as well as a calibrated fine down feed built in, allowing operators to drill and mill to precise, repeatable depths with confidence.
- Is a stand included with the JMD-45GH?
- No. The Mill Drill Stand (p/n 350045), which is shown in some product images, is optional and not included with the machine. It is available as a separate accessory.
