Product Description
The Simpson Strong-Tie SP2 Stud-Plate Tie (Model SP2) is a 3-1/2-in. x 6-5/8-in. galvanized connector engineered specifically for double-top-plate-to-stud connections, providing reliable uplift resistance in wood-framed construction. Part of Simpson Strong-Tie's stud-plate tie series, the SP2 delivers a positive, code-recognized connection between the stud and the double top plate, helping structures withstand wind and seismic forces with confidence.
Key Features
- Features embossments that strengthen the stud-to-plate connection
- Designed to resist wind and seismic forces
- Can be used before or after installation including in retrofit applications
- Stud size: nominal 2x
- Made from 20-gauge steel
- Galvanized (G90) for corrosion resistance
- Angled holes provide a positive connection from the stud to the plates
Specifications
- Model Number: SP2
- Width: 3-1/2 in.
- Length: 6-5/8 in.
- Gauge: 20
- Coating/Finish: Zinc Galvanized, G90
- Member Size: Nominal 2x
- Installation Fasteners (sold separately): Install with (12) 0.148 x 3-in. nails
- Country of Origin: United States
Approved Applications
- Double-top-plate-to-stud connections
- Uplift resistance in wood-framed construction
- New construction installations
- Retrofit applications where stud-to-plate connections require reinforcement
- Structures requiring resistance to wind and seismic forces
Frequently Asked Questions
- What is the SP2 designed to connect?
- The SP2 is designed for the double-top-plate-to-stud connection, providing uplift resistance between the stud and the double top plate in wood-framed construction.
- How does the SP2 differ from the SP1?
- While both the SP1 and SP2 are stud-to-plate connections designed to resist uplift, the SP1 is designed specifically for sill-to-stud connections, whereas the SP2 is engineered for the double-top-plate-to-stud connection.
- Can the SP2 be used in retrofit applications?
- Yes. The SP2 can be used before or after installation, including in retrofit applications, making it a versatile solution for both new construction and existing structures that need reinforced stud-to-plate connections.
- What fasteners are required to install the SP2?
- The SP2 should be installed with (12) 0.148 x 3-in. nails. One of the nails is driven at a 45 deg. angle through the stud into the plate for a positive, secure connection.
