Product Features
Product Description
Simpson AT3G10 AT-3G 9.5-oz. High-Strength Hybrid Acrylic Anchoring Adhesive Cartridge with Nozzle by Simpson Strong-Tie is a hybrid, acrylic-based adhesive engineered for anchoring threaded rod and rebar into cracked and uncracked concrete. Ideal for cold weather and wet concrete applications, AT-3G dispenses easily and offers a fast curing time for same-day bolt up. It can be specified for a wide range of in-service temperatures, and maintains its strong bond strength in extreme environments for ultimate design and jobsite flexibility. Tested and code compliant with the IBC and IRC, AT-3G hybrid adhesive is easy to install with the conventional blow-brush-blow hole cleaning method. AT-3G serves as the direct replacement for the discontinued AT-XP.
Key Features
- Excellent for use in cold weather conditions or applications where fast cure is required
- Recognized per ICC-ES AC308 for threaded rod and rebar anchoring, along with post-installed rebar development and splice length design provisions
- Conventional blow-brush-blow hole cleaning technique using a wire brush - no power brushing required
- Base material installation temperatures down to 0 deg. Fahrenheit (-18 deg. Celsius)
- Use in grout-filled CMU construction
- Use of a vacuum in lieu of compressed air for hole cleaning
- Installation into oversized holes
- Installation in holes drilled with diamond core bits
- 9.5-oz. coaxial cartridge
- Tested in accordance with ICC-ES 308, ACI 355.4 and applicable ASTM test methods
Specifications
- MPN: AT3G10
- Brand: Simpson Strong-Tie
- Capacity: 9.5 oz. (16.9 cubic in.)
- Cartridge Type: 9.5-oz. coaxial cartridge
- Minimum Installation Temperature: 0 deg. Fahrenheit (-18 deg. Celsius)
- Compatible Dispensing Tool: Simpson Strong-Tie CDT10S
- Mixing Nozzle: AMN19Q
- Country of Origin: DE
Approved Applications
- Concrete: Cracked and Uncracked
- Concrete Block: Grouted (Grout-Filled CMU Construction)
- Mass Timber / Cross-Laminated Timber
- Seismic (New Construction)
- Seismic Retrofit
- Water / Wastewater Facilities
What's Included
Each pack contains (1) AT3G10 High-Strength Hybrid Acrylic Adhesive, AMN19Q mixing nozzle.
Frequently Asked Questions
- What is the lowest temperature at which AT-3G can be installed?
- AT-3G supports base material installation temperatures down to 0 deg. Fahrenheit (-18 deg. Celsius), making it well suited for cold weather jobsite conditions where other adhesives may not perform adequately.
- What hole cleaning method is required for AT-3G?
- AT-3G uses the conventional blow-brush-blow hole cleaning technique with a wire brush - no power brushing is required. A vacuum may also be used in lieu of compressed air for hole cleaning.
- What dispensing tool and mixing nozzle should be used with AT-3G?
- AT-3G should be installed using the Simpson Strong-Tie CDT10S dispensing tool. Use only Simpson Strong-Tie mixing nozzles - the included AMN19Q mixing nozzle - in accordance with Simpson Strong-Tie instructions. Modification or improper use of the mixing nozzle may impair AT-3G adhesive performance.
- What code standards is AT-3G recognized under?
- AT-3G is recognized per ICC-ES AC308 for threaded rod and rebar anchoring, along with post-installed rebar development and splice length design provisions. It has also been tested in accordance with ICC-ES 308, ACI 355.4, and applicable ASTM test methods, and is code compliant with the IBC and IRC.
Downloads and Resources
- AT-3G (Direct Replacement for the discontinued AT-XP) is a hybrid, acrylic-based adhesive for anchoring threaded rod and rebar into cracked and uncracked concrete. Ideal for cold weather and wet concrete applications, AT-3G dispenses easily and offers a fast curing time for same-day bolt up.
- Safety Data Sheets for AT-3G
- AT-3G (Direct Replacement for the discontinued AT-XP) is a hybrid, acrylic-based adhesive for anchoring threaded rod and rebar into cracked and u
Related Products
- CDT10S - Manual Dispensing Tool for AT-3G Adhesive
