Product Description
Simpson Strong-Drive SDCFC TIMBER-CFC Screw - 0.315 in. x 6 1/4 in., T40, E-Coat by Simpson Strong-Tie is a heavy-duty structural fastener engineered for demanding timber construction applications. Designed for use with large members including mass timber, cross-laminated timber, glulam beams, and engineered wood assemblies, this cylinder-head screw combines a fully threaded shank with a SawTooth point to deliver exceptional withdrawal resistance and fast, clean installation. The black e-coat electrocoating finish provides a construction-durable nonmetallic corrosion barrier suited for interior dry-service environments, while the deep T40 6-lobe drive recess ensures reliable torque transfer with reduced cam-out risk.
Key Features
- Compact cylinder head design - helps countersink the screw flush for a clean exposed finish or a fully concealed appearance when driven below the surface
- Heavy-duty, fully threaded shank - maximizes withdrawal resistance along the entire fastener length, providing superior holding power in wood-to-wood connections
- SawTooth point - enables fast starts and easy driving while reducing installation torque, eliminating the need for predrilling in most applications and speeding up workflow
- Black e-coat electrocoating finish - delivers a construction-durable nonmetallic coating that resists corrosion in interior dry-service applications while enhancing aesthetics with a consistent black color
- Deep T40 6-lobe recess - provides a secure, positive drive engagement that reduces cam-out and driver slippage, improving installation accuracy and efficiency
- Optimized hardness profile - works together with the e-coat finish to help mitigate the risk of brittle fracture, supporting reliable long-term structural performance
- Compliant with CSA O86:24 hydrogen embrittlement requirements - meets Canadian structural engineering standards, giving specifiers and builders added confidence in code compliance
Why This Product
- Built specifically for large timber members - the fully threaded shank and SawTooth point make this screw a reliable choice for mass timber, glulam, and engineered wood fastening where withdrawal resistance and driving ease are both critical
- Eliminates predrilling in most applications - the SawTooth point reduces installation torque and allows direct driving into heavy timber without a pilot hole, saving time on large framing projects
- Engineered for interior structural integrity over time - the optimized hardness profile combined with the e-coat finish addresses brittle fracture risk, providing long-term performance confidence in wood-to-wood structural connections
- Versatile across a wide range of structural tasks - approved for applications from beam reinforcement and butt joist fastening to fastening Simpson Strong-Tie connectors, reducing the need for multiple fastener types on a single job site
Specifications
- Brand: Simpson Strong-Tie
- Product Name: Strong-Drive SDCFC TIMBER-CFC Screw
- Length: 6 1/4 in.
- Shank Diameter: 0.230 in.
- Head Diameter: 0.400 in.
- Thread Length: 5 7/8 in.
- Drive Type: T40 6-Lobe
- Head Type: Cylinder Head
- Point Type: SawTooth Point
- Coating: E-coat Electrocoating
- Finish: E-coat Electrocoating
- Color: Black
- Category: Fasteners - Interior Wood Screws - Hand-Drive Screw
Available Pack Options
- SDCFC8X160-R50: 50 Pk - includes T40, 6-lobe driver bit (replacement bit: BIT40T-134-R2)
- SDCFC8X160: 250 Pk - includes T40, 6-lobe driver bit (replacement bit: BIT40T-134-R2)
Approved Applications
- Engineered Wood
- Fastening Wood-to-Wood
- Timber Framing
- Beam Reinforcement
- Fastening Wall-to-Wall
- Fastening Support Beams
- Heavy Timber
- Glulam
- Fastening Butt Joists
- Mass Timber / Cross-Laminated Timber
- Engineered Wood - Multi-Ply Fastening
- Fastening Simpson Strong-Tie Connectors
What's Included
- T40, 6-lobe driver bit (replacement bit: BIT40T-134-R2)
