Product Description
Simpson LGUM26-2-SDS LGUM High-Capacity Girder Hanger for Masonry for Double 2x6 with Screws/Anchors is a heavy-duty, face-mount hanger engineered by Simpson Strong-Tie for hanging double 2x6 girders, beams, and joists onto concrete or grouted CMU masonry walls. Built from 12-gauge steel with a G90 galvanized finish for enhanced corrosion resistance, this high-capacity hanger simplifies installation by including all required fasteners - Strong-Drive SDS Heavy-Duty Connector screws for the wood member and Titen HD anchors for the masonry wall - right in the box.
Key Features
- Attach hanger to a concrete or grouted CMU wall using Titen HD anchors
- Titen HD is not recommended for exposed exterior applications
- Provide moisture barrier between beam and wall per jurisdictional requirements
- Installation is made easier using Simpson Strong-Tie Strong-Drive SDS screws (provided) into the wood member and Titen HD anchors (provided) into the masonry
- Made from 12-gauge steel for high-capacity load performance
- Galvanized (G90) for extra corrosion resistance
- Supports double 2x6 nominal joist/girder size
- Manufactured in the United States
Specifications
- MPN: LGUM26-2-SDS
- Member Size: Double 2x6
- Seat Width: 3-5/16 in.
- Height: 5-7/16 in.
- Gauge: 12
- Coating/Finish: Zinc Galvanized, G90
- Width: 3-5/16 in.
- Country of Origin: United States
Approved Applications
- Hanging double 2x6 girders and beams onto concrete walls
- Hanging double 2x6 girders and beams onto grouted CMU (concrete masonry unit) walls
- Interior masonry-to-wood structural connections where a moisture barrier is provided between beam and wall per jurisdictional requirements
What's Included
Each pack contains (1) LGUM26-2-SDS Double Masonry Girder Hanger, Strong-Drive SDS Heavy-Duty Connector screws and Titen HD anchors.
Options
- Contact us for Configurable Options and Special orders
Frequently Asked Questions
- What type of wall can the LGUM26-2-SDS be attached to?
- This hanger is designed for use with concrete or grouted CMU (concrete masonry unit) walls. Titen HD anchors (included) are used to attach the hanger to the masonry surface.
- Are fasteners included with this hanger?
- Yes. The LGUM26-2-SDS includes both Strong-Drive SDS Heavy-Duty Connector screws for fastening into the wood member and Titen HD anchors for fastening into the masonry wall, so no additional hardware needs to be sourced separately.
- Can this hanger be used in exposed exterior masonry applications?
- No. The Titen HD anchors included with this hanger are not recommended for exposed exterior applications. It is intended for interior or protected masonry installations.
- Is a moisture barrier required when installing this hanger?
- Yes. A moisture barrier should be provided between the beam and the wall per jurisdictional requirements. Always consult local building codes and requirements before installation.
Note: Product dimensions and/or screw or bolt holes may differ from picture.
