Product Description
The Simpson 4 x 14 Top-Flange Face Mount Hanger (Model No. HUS414TF) is a heavy-duty hybrid joist hanger engineered to combine the structural advantages of both face-mount and top-mount hanger designs. Fabricated from Zinc Galvanized (G97) steel and sized for 4x14 lumber, this top-flange hanger delivers exceptional load performance through double-shear nailing, where each nail engages both the joist and the header to distribute loads across two points per joist nail for superior strength and reliability.
Key Features
- Features an embossed top flange that provides additional connection strength
- Designed with double-shear nailing combined with face-nailing for high loads
- HUSTF-series hangers are tested, load rated and code compliant
- Economical design - cannot be modified
- Zinc Galvanized (G97) coating for corrosion resistance
- Made in the United States
Specifications
- Model No.: HUS414TF
- Joist Size: 4x14
- Gauge: 14
- Width: 3-9/16 in.
- Height: 13-1/8 in.
- TF: 2-1/16 in.
- Coating/Material: Zinc Galvanized, G97
- Country of Origin: United States
Approved Applications
- Face-mount and top-mount hybrid joist hanger applications requiring high load capacity
- Structural connections using 4x14 lumber joists and headers
- Not acceptable for nailer or welded applications
Options
Some products available in HDG. Contact us for Configurable Options and Special orders.
Frequently Asked Questions
- What size lumber is the HUS414TF designed to support?
- The HUS414TF is designed for use with 4x14 joist lumber, with a width of 3-9/16 in. and a height of 13-1/8 in. to properly seat and secure that lumber size.
- What fasteners are required for installation?
- Use all specified fasteners. Standard installation requires 0.162" x 3-1/2" nails. With 3x carrying members, use 0.162" x 2-1/2" nails in the header and 0.162" x 3-1/2" nails in the joist.
- Can the HUS414TF be used in nailer or welded applications?
- No. The HUS414TF is not acceptable for nailer or welded applications. Additionally, this hanger cannot be modified in the field.
- What is the coating on the HUS414TF and is it available in other finishes?
- The HUS414TF comes with a Zinc Galvanized, G97 coating as standard. Some products in this series are available in HDG (Hot-Dip Galvanized)..
Note: Product dimensions and/or Screw or Bolt holes may differ from picture. Please see item description for specifications.
