Product Description
Simpson 24 in. Heavy Twist Strap, Reverse Bend (HTS24-REV) - is a Simpson Strong-Tie engineered tension connector designed to resist heavy uplift loads at the rafter or heel of a truss. Featuring a reverse-bend configuration and a small bend section that minimizes interference at transition points between members, this strap delivers a reliable, economical tension connection without requiring the strap to be wrapped over the truss to achieve the allowable load.
Key Features
- Available with the bend reversed for versatile installation orientations
- Straps do not need to be wrapped over the truss to achieve the allowable load
- Versatile with many lengths offered to fit the specific application
- Small bend section reduces interference at the transition points between the two members
- Provides a tension connection between two members to resist heavy uplift loads at the rafter or heel of a truss
- Zinc Galvanized G90 coating for corrosion resistance
- Made in the United States
Specifications
- Model Number: HTS24-REV
- Bend Type: Reverse bend
- Length: 24 in.
- Gauge: 14
- Thickness: 68 mil
- Coating/Material: Zinc Galvanized, G90
- Country of Origin: United States
Approved Applications
- Tension connection between two structural members
- Heavy uplift load resistance at the rafter
- Heavy uplift load resistance at the heel of a truss
Frequently Asked Questions
- What is the purpose of the reverse bend on the HTS24-REV?
- The reverse bend configuration allows the strap to be installed in orientations where a standard bend would not be suitable, reducing interference at the transition points between the two members being connected.
- Does the strap need to be wrapped over the truss to achieve the allowable load?
- No. Straps do not need to be wrapped over the truss to achieve the allowable load, simplifying installation while still delivering the full rated performance.
- What fasteners are required to install the HTS24-REV?
- Installation requires Nails 0.148 x 3" and Nails 0.148" x 1-1/2". Use all specified fasteners, with half into each member being connected, to achieve the listed loads.
- What coating does the HTS24-REV have, and why does it matter?
- The HTS24-REV features a Zinc Galvanized, G90 coating. This coating provides corrosion resistance, helping to maintain structural integrity and long-term performance in typical construction environments.
