Freud 300mm Thin to Medium Aluminum and Non-Ferrous Saw Blade with Mechanical Clamping is an 88-tooth carbide-tipped circular saw blade engineered for precision cutting of aluminum, non-ferrous metals, and polymeric materials. Designed for use on miter saws, stationary table saws, and double miter saws, this 300mm blade delivers clean, controlled cuts in drawn products and tubes with a thickness between 2 and 5 mm, as well as polymeric panels up to 20 mm. Whether you are working with aluminum extrusions, brass, copper, vinyl, or plastic sheeting, this blade is built to perform with accuracy and longevity on demanding workshop applications.

Key Features

• Flat-triple chip tooth (TCG) grind with a 5 deg. hook angle - the triple chip geometry produces a smooth, controlled cut on non-ferrous metals and plastics while the positive cutting angle reduces chipping and material tear-out.
• Silver I.C.E. Coating on the blade surface - this coating actively prevents material build-up and keeps the blade running cooler and cleaner, extending cutting performance and reducing the need for frequent cleaning between cuts.
• Silent Sawblade construction - noise-dampening design minimizes vibration and operational sound levels, contributing to a more comfortable and controlled cutting environment during extended use.
• 88 carbide teeth on a 300mm diameter blade - the high tooth count produces fine, precise cuts in thin-to-medium aluminum profiles and non-ferrous tubing, reducing finishing work after the cut.
• 3.5mm kerf with a 3mm plate - the slim kerf removes less material per pass, which means less waste and reduced load on the motor of compatible saw equipment.
• 30mm arbor with dual pinhole configurations (2/9/46.4 + 2/10/60) - the mechanical clamping system and multiple pinhole patterns ensure secure, stable mounting across a range of compatible saw platforms.
• Compatible with Plastic, Vinyl, Aluminum, Brass, and Copper - broad material compatibility means this single blade handles multiple non-ferrous and polymeric cutting tasks, reducing the need to swap blades between jobs.

Why This Product

• The Silver I.C.E. Coating keeps the blade surface clean and cooler during cuts, which directly translates to longer blade life and more consistent results when cutting aluminum, brass, copper, and similar materials.
• With an 88-tooth TCG grind and a positive 5 deg. hook angle, this blade is purpose-matched for thin-to-medium drawn products and tubes (2-5 mm) as well as polymeric panels up to 20 mm - covering a wide range of workshop cutting needs in one blade.
• The Silent Sawblade design reduces vibration during operation, which supports cleaner cuts and a more controlled working experience on miter saws and stationary table saws alike.
• Dual pinhole configurations (2/9/46.4 + 2/10/60) combined with mechanical clamping provide a secure, properly seated fit on compatible equipment, helping maintain blade alignment and cut accuracy over repeated use.

Specifications

• Brand: Freud
• Diameter: 300mm
• Teeth: 88
• Arbor: 30mm
• Kerf: 3.5mm
• Plate: 3mm
• Hook Angle: 5 deg.
• Grind: TCG
• Pinholes: 2/9/46.4 + 2/10/60
• Compatible Tools: Miter Saw; Stationary Table Saw; Double Miter Saw
• Compatible Materials: Plastic; Vinyl; Aluminum; Brass; Copper
• Usage: To cut drawn products and tubes with a thickness included between 2 and 5 mm, as well as polymeric panels up to 20 mm.
• Pack Quantity: 1
• Country of Origin: Italy

Approved Applications

• Sawblades to cut aluminum and non-ferrous metals

Frequently Asked Questions

What materials can this blade cut?

This blade is rated for cutting Plastic, Vinyl, Aluminum, Brass, and Copper. It is specifically designed for drawn products and tubes with a thickness between 2 and 5 mm, as well as polymeric panels up to 20 mm.

Which saws is this blade compatible with?

This 300mm blade is designed for use on a Miter Saw, Stationary Table Saw, and Double Miter Saw. The 30mm arbor and dual pinhole configurations (2/9/46.4 + 2/10/60) support mechanical clamping on compatible equipment.

What does the Silver I.C.E. Coating do?

The Silver I.C.E. Coating prevents build-up on the blade surface and keeps the blade running cooler and cleaner during cutting operations. This helps maintain cutting performance and reduces the frequency of blade cleaning or replacement.

What does the TCG grind mean for cutting performance?

TCG stands for triple chip grind, which is the tooth geometry used on this blade. The flat-triple chip tooth with positive cutting angle is suited for cutting non-ferrous metals and polymeric materials, producing controlled cuts with reduced chipping on the workpiece.
