Product Features
Product Description
JET 10-PT, 10 Ton Heavy Duty Manual Trolley from JET delivers a powerful 22,000 lb capacity solution for demanding overhead material handling operations. Engineered with a welded heavy gauge steel frame and a powder coat finish, this manual push trolley is built to provide maximum durability and long-term protection in industrial and commercial environments. Its wide beam compatibility and smooth-rolling wheel system make it a dependable choice for workshops, warehouses, and production facilities that rely on consistent, precise load movement.
Key Features
- Built-in bumper guards on the side plates increase safety and extend trolley life
- Complies with OSHA Regulations, ANSI / ASME B30.11 and B30.17 standards
- Easily adjustable to wide-flange H-beams, standard I-beams, or curved track with the included spacer washers
- Hardened large steel wheels and thicker double sealed lubricated ball bearings provide smooth movement
- Welded heavy gauge steel frame and powder coat finish provide maximum durability and protection
Specifications
- MPN: JT9-252060
- Stock Number: 252060
- Load Capacity (Tons): 10
- Capacity (Lbs.): 22,000
- Wheel Diameter (In.): 6
- Minimum Beam Flange Width (In.): 4-3/4
- Maximum Beam Flange Width (In.): 8
- Minimum Beam Height (In.): 6
- Minimum Beam Curve Radius (In.): 67
- Hook Mount Headroom (In.): 10-5/6
- Max. Hook Size (W/in.): 3-2/9
- Overall Dimensions (L x W x H / in.): 18 x 17 x 11-3/5
- Weight (Lbs.): 202
- Country of Origin: China
- Prop 65: Cancer and Reproductive Harm
Frequently Asked Questions
- What is the maximum load capacity of this JET manual trolley?
- This trolley is rated for a maximum load capacity of 22,000 lbs (10 tons), making it well suited for heavy-duty overhead lifting and material handling applications.
- What types of beams is this trolley compatible with?
- The JET 10-PT manual trolley is easily adjustable to wide-flange H-beams, standard I-beams, or curved track. The included spacer washers allow the beam flange width to be set anywhere from 4-3/4 inches to 8 inches, accommodating a variety of overhead beam configurations.
- What safety and compliance standards does this trolley meet?
- This trolley complies with OSHA Regulations and ANSI / ASME B30.11 and B30.17 standards. Additionally, the built-in bumper guards on the side plates are designed to increase safety and extend the working life of the trolley.
- What construction features contribute to smooth and durable operation?
- The trolley features hardened large steel wheels and thicker double sealed lubricated ball bearings that provide smooth movement along the beam. The welded heavy gauge steel frame and powder coat finish further contribute to maximum durability and long-term protection against wear and corrosion.
