The Simpson RPS28 RPS 28-5/16 in. 16-Gauge Galvanized Retrofit Strap Tie by Simpson Strong-Tie is a heavy-duty repair strap engineered for wood members where pipes and ducts have been installed, restoring structural integrity to cut or notched framing members. Fabricated from 16-gauge steel with a G90 zinc galvanized coating for lasting corrosion resistance, this retrofit strap tie meets IBC, IRC, and City of Los Angeles code requirements for HVAC and pipes in walls, making it a trusted solution for both repair and new construction applications.

Key Features

• Repair strap for wood members where pipes and ducts are installed
• Fits on the narrow face of a 2x member
• Fasten where plates or soles are cut, at wall intersections or as a ridge tie
• Staggered nail pattern for optimized load transfer and reduced splitting
• Width: 1-1/2 in.
• Length: 28-5/16 in.
• Made from 16-gauge steel
• Galvanized (G90) for corrosion resistance
• Meets IBC, IRC and City of Los Angeles code requirements for HVAC and pipes in walls
• Made in the United States

Specifications

• Model Number: RPS28
• Gauge: 16
• Width: 1-1/2 in.
• Length: 28-5/16 in.
• Coating/Finish: Zinc Galvanized, G90
• Installation Fasteners: Install with (12 - 16) 0.162 in. x 2-1/2 in. nails (sold separately)
• Country of Origin: United States

Approved Applications

• Reinforcing top plates in wall framing where pipes or ducts have been cut through
• Fastening where plates or soles are cut due to HVAC or plumbing installations
• Use at wall intersections to tie framing members together
• Ridge tie applications requiring a low-profile, narrow-face strap solution
• Code-compliant repair of wood members per IBC, IRC and City of Los Angeles requirements

Frequently Asked Questions

What is the RPS28 designed to repair?

The RPS28 is a retrofit strap tie specifically designed for wood members where pipes and ducts have been installed, such as when a top plate or sole plate has been cut or notched to accommodate HVAC lines or plumbing. It restores the structural connection of the framing member.

Which building codes does the RPS28 comply with?

The RPS28 meets IBC (International Building Code), IRC (International Residential Code), and City of Los Angeles code requirements for HVAC and pipes in walls, making it suitable for permitted repair and construction projects in a wide range of jurisdictions.

How does the RPS28 install, and what fasteners are required?

The RPS28 is installed on the narrow face of a 2x lumber member using its staggered nail pattern. It requires (12 - 16) 0.162 in. x 2-1/2 in. nails for proper installation. The staggered pattern helps distribute load and minimizes the risk of wood splitting.

What corrosion protection does the RPS28 offer?

The RPS28 features a G90 zinc galvanized coating, which provides a robust level of corrosion resistance suitable for standard interior framing repairs and connections. For applications requiring additional corrosion protection, such as at sill plates, the ZMAX-coated variant (RPS28Z) is recommended instead.

Note: Product dimensions and/or screw or bolt holes may differ from picture. Please see item description for specifications.
