The Simpson LTHJA26 Multiple-Truss Hip/Jack Hanger is an 18-gauge galvanized steel connector from Simpson that delivers reliable performance for light hip/jack load applications at the lowest installed cost in its category. Engineered as a lighter-capacity alternative to the THJA26, this hanger is purpose-built for nominal 2x6 joist members and requires attachment to a double-girder truss. Simpson Strong-Tie connectors are engineered, tested, and manufactured to the highest quality standards, making them the trusted choice of engineers and contractors on residential and light commercial framing projects alike.

Key Features

• Lowest installed cost for light hip/jack load applications - keeps material and labor costs in check without sacrificing structural integrity on qualifying hip and jack truss connections
• Lighter version of the THJA26 - purpose-sized for light load conditions, so you are not over-engineering or overpaying for capacity you do not need
• Designed for attachment to a double-girder truss - ensures proper load transfer and nail penetration, keeping the installation code-compliant and structurally sound
• Nominal 2x6 joist compatibility - matches directly to standard 2x6 framing members, simplifying layout and reducing on-site fitment time
• 18-gauge steel construction - provides the structural rigidity needed for light hip/jack framing while keeping the connector lightweight and easy to handle
• G90 zinc galvanized coating - adds a durable layer of corrosion resistance, making this hanger suitable for a variety of construction environments where moisture exposure is a concern

Why This Product

• Cost-effective solution for light hip/jack framing - the LTHJA26 is specifically designed to offer the lowest installed cost among connectors in its category, making it an efficient choice for budget-conscious projects that still demand reliable performance
• Trusted Simpson engineering behind every connector - Simpson Strong-Tie connectors are engineered and tested to perform, giving contractors and engineers confidence that the product meets established quality and safety standards
• Corrosion-resistant finish extends service life - the G90 zinc galvanized coating provides extra corrosion resistance, helping the connector hold up over time in conditions where bare steel would be vulnerable
• Straightforward installation with common fasteners - installs with 10d and 10d x 1-1/2 in. nails, which are standard on most job sites, reducing the need for specialty hardware and keeping the installation process simple and efficient

Specifications

• Model Number: LTHJA26
• Gauge: 18
• Member Size: 2x6
• Coating: Zinc Galvanized, G90
• Finish: Zinc Galvanized, G90
• Install With: 10d and 10d x 1-1/2in. Nails
• Country of Origin: United States

Frequently Asked Questions

What type of truss is required when installing the LTHJA26?

The LTHJA26 must be attached to a double-girder truss to allow for the required minimum nail penetration. All members must be fastened together to act as a single unit.

What is the difference between the LTHJA26 and the THJA26?

The LTHJA26 is a lighter-capacity version of the THJA26. It is designed for light hip/jack load applications and offers the lowest installed cost among comparable connectors in its category.

What fasteners are required to install the LTHJA26?

Install with 10d and 10d x 1-1/2in. Nails. The 0.148" x 1-1/2" nails must be installed into the bottom of the hip members through the bottom of the hanger seat to achieve the listed table loads.

What corrosion protection does the LTHJA26 provide?

The LTHJA26 features a G90 zinc galvanized coating, which provides extra corrosion resistance, making it suitable for use in a variety of construction environments.
