Product Description
The Simpson Strong-Tie FGTRHR Face-Mount Retrofit Girder Tiedown, Right Corner Hip is a moderate- to high-load capacity connector engineered for right-direction corner hip applications in both new construction and retrofit projects. Designed to resist uplift forces at critical roof framing connections, this face-mount girder tiedown arrives with all required fasteners included, so installers can move directly from unboxing to installation without sourcing additional hardware.
Key Features
- Right-direction corner hip configuration - purpose-built geometry ensures correct fit and load transfer at right corner hip intersections; for left-hand applications, order the FGTRHL instead
- Strong-Drive SDS screws included - Simpson Strong-Tie Strong-Drive SDS Heavy-Duty Connector screws and Titen HD heavy-duty screw anchors ship with the connector, eliminating a separate fastener purchase and keeping the job on schedule
- Double-installation screw hole layout - screw holes are configured to allow for double installation on a two-ply (minimum) truss, giving contractors the option to pair two connectors for higher uplift capacity when the structural demand requires it
- Heavier plate gauge at key stress points - a 7-gauge strap paired with a 3-gauge plate delivers the structural robustness needed for moderate- to high-load tiedown duty
- Powder-coated gray finish - the factory-applied powder coating provides a consistent, durable surface that helps protect the connector during handling and installation
Why This Product
- New construction and retrofit versatility - the FGTR product line is engineered for both new builds and existing-structure upgrades, making this connector a practical choice whether a project starts from the ground up or involves strengthening a roof framing system already in place
- Complete, ready-to-install package - because the specified Simpson Strong-Tie fasteners ship in the box, there is no need to cross-reference a separate fastener schedule or make an additional order before work can begin
- Scalable uplift resistance - the double-installation capability on a two-ply (minimum) truss means a single connector model can serve a range of load requirements, reducing the need to source a different product when uplift demands increase
- Engineered and tested to Simpson Strong-Tie quality standards - the connector is manufactured to the same rigorous engineering and testing standards that define the Simpson Strong-Tie line, supporting confidence in performance at the corner hip - one of the most structurally complex points in a hip roof assembly
Specifications
- Model Number: FGTRHR
- Brand: Simpson Strong-Tie
- Application: Right corner hip
- Gauge: Strap 7; plate 3
- Coating/Finish: Powder Coating, Gray
- Country of Origin: United States
What's Included
Each pack contains (1) FGTRHR Face-Mount Retrofit Girder Tiedown, (18) 1/4-in. x 3-in. Strong-Drive SDS Heavy-Duty Connector screws and (2) 1/2-in. x 5-in. Titen HD heavy-duty screw anchors.
Downloads and Resources
Note: Product dimensions and/or screw or bolt holes may differ from picture. Please see item description for specifications.
Frequently Asked Questions
What is the difference between the FGTRHR and the FGTRHL?
The FGTRHR is designed for right-direction corner hip applications. For left-hand corner hip applications, the FGTRHL should be ordered instead.
Can the FGTRHR be used in retrofit applications?
Yes. The FGTR product line is designed for both new construction and retrofit applications, making the FGTRHR a versatile solution for projects that require upgrading existing structures.
Can the FGTRHR be installed in pairs to increase uplift capacity?
Yes. The screw holes are configured to allow for double installation on a two-ply (minimum) truss, enabling two connectors to be used together to achieve a higher uplift capacity.
Does the FGTRHR come with the required fasteners?
Yes. The FGTRHR includes (18) 1/4-in. x 3-in. Strong-Drive SDS Heavy-Duty Connector screws and (2) 1/2-in. x 5-in. Titen HD heavy-duty screw anchors needed for installation.
