Product Features
Product Description
Key Features
- Uniformly brazed carbide inserts result in longer bit life
- Chromium-nickel-molybdenum steel alloy body ensures hammering quality and extended service life
- Heat-treatment procedures and shot-peened finish increase surface hardness, drilling speed, reduces drill bit wear and improves resistance to bending forces
- Drill bits conform to ANSI Standard B212.15
- Chisel-shaped drill-bit head penetrates the material and directs concrete dust into the multi-flute spiral
- High-volume, multi-flute spiral quickly channels concrete dust from the hole to improve drilling speed
- Solid-tip carbide drill bit construction for reliable, consistent performance
- SDS-plus shank for secure, tool-free bit changes and positive power transfer
Specifications
- Model Number: MDPL02506S
- Brand: Simpson Strong-Tie
- Head Type: Solid-Tip Carbide Drill Bit
- Shank Type: SDS-plus
- Diameter: 1/4 in.
- Length: 6-1/4 in.
- Drilling Depth: 4 in.
- Material: Hardened Steel
- Standard Compliance: ANSI Standard B212.15
- Country of Origin: DE
Frequently Asked Questions
- What type of shank does the MDPL02506S use, and which rotary hammers is it compatible with?
- The MDPL02506S features an SDS-plus shank, which is the standard shank type used in a wide range of rotary hammer drills. This shank design allows for tool-free bit changes and provides a secure, positive connection for efficient power transfer during drilling.
- What is the maximum drilling depth this bit can achieve?
- This bit provides a drilling depth of 4 in. It has an overall length of 6-1/4 in. and a diameter of 1/4 in., making it suitable for applications requiring moderate-depth holes in concrete and masonry.
- How does the bit's construction help extend its service life?
- The bit features uniformly brazed carbide inserts for longer bit life, a chromium-nickel-molybdenum steel alloy body for hammering quality and extended service life, and heat-treatment procedures combined with a shot-peened finish that increase surface hardness, reduce drill bit wear, and improve resistance to bending forces.
- Does this drill bit meet any recognized industry standards?
- Yes. The MDPL02506S conforms to ANSI Standard B212.15, ensuring it meets established dimensional and performance tolerances required for professional-grade SDS-plus carbide drill bits.
Note: Product dimensions may differ from picture. Please see the item description above for specifications.
