Product Description
The Simpson HGUS28-4 Galvanized Face-Mount Joist Hanger for Quad 2x8 Members is a heavy-duty connector engineered by Simpson Strong-Tie for structural applications where higher load values are required. Designed to provide solid support underneath the joist, rafter, or beam, this face-mount hanger creates a strong, reliable connection for quadruple 2x8 assemblies. Built from 12-gauge steel with a G90 zinc galvanized finish, it is well suited for demanding framing applications where both load performance and corrosion resistance are priorities.
Key Features
- Double-shear nailing design - distributes the load through two points on each joist nail, delivering greater strength and structural confidence in high-load connections
- Fewer nails required with standard 16d common nails - speeds up installation and eliminates the need for specialty fasteners, saving time and reducing material costs on the job
- 12-gauge steel construction - provides the added thickness and rigidity needed to handle the demands of quadruple 2x8 member applications
- G90 zinc galvanized coating - offers extra corrosion resistance, helping the hanger hold up in moisture-exposed or outdoor framing environments
- Tabs must not be bent or removed - preserving the factory geometry ensures the hanger performs as engineered and maintains its rated connection strength
Why This Product
- Built for high-load framing needs - the HGUS series is specifically designed for applications where higher load values are needed, making this hanger a dependable choice when standard joist hardware falls short
- Faster, simpler installation without sacrificing strength - the double-shear nailing system allows contractors to use fewer nails and standard fasteners while still achieving a strong, code-worthy connection
- Corrosion-resistant finish extends service life - the G90 galvanized coating adds a layer of durability that helps protect the connection in environments where moisture or humidity is a concern
- American-made quality from a trusted connector brand - Simpson Strong-Tie manufactures this hanger to consistent tolerances, giving builders confidence in the fit and performance of every installation
Specifications
- MPN: HGUS28-4
- Member Size: Quad 2x8
- Gauge: 12
- Height (H): 7-3/16 in.
- Coating: Zinc Galvanized, G90
- Finish: Zinc Galvanized, G90
- Install With: 16d common nails
- Country of Origin: United States
Options
- Contact us for Configurable Options and Special orders
Note: Product dimensions and/or nail holes may differ from picture. Please see item description for specifications.
Frequently Asked Questions
What size member is the HGUS28-4 designed to support?
The HGUS28-4 is designed for a nominal joist size of Quad 2x8, making it suitable for applications that require support of quadruple 2x8 members.
What type of nails should be used to install the HGUS28-4?
The HGUS28-4 should be installed with 16d common nails. Its double-shear nailing design also allows for the use of fewer nails while still maintaining a strong connection.
What is the benefit of the double-shear nailing design?
Double-shear nailing distributes the load through two points on each joist nail, providing greater strength. This design also allows for faster installation and the use of standard nails for all connections.
What corrosion protection does the HGUS28-4 offer?
The HGUS28-4 features a G90 zinc galvanized coating, which provides extra corrosion resistance and helps extend the service life of the hanger in demanding environments.
