The Freud 13/16" Precision Shear Forstner Bit is a professional-grade boring tool engineered for woodworkers who demand clean, flat-bottom holes with minimal tearout. Designed for use in a drill press or handheld drill, this 13/16" diameter bit cuts through hardwoods, softwoods, veneered plywood, solid surface, and composites with exceptional precision. Whether you are drilling pocket holes, overlapping holes, or clean through-bores, the Freud Precision Shear series delivers smooth results that traditional Forstner bit designs simply cannot match.

Key Features

• Razor sharp serrated edge for fast and flawless cutting - a double-ground, razor-sharp serrated edge slices continuously throughout the full rotation of the bit, dramatically reducing splintering and chipping so your workpiece surfaces stay clean and ready to finish without extra sanding.
• Unique geometric multi-edge design - multiple cutting edges produce greater shearing action compared to conventional Forstner bit designs, allowing for faster rotational speeds and more efficient material removal so you spend less time at the drill press.
• Quality forged construction for extended life - forged bit body increases durability and resistance to wear, meaning the bit stays true longer and delivers consistent performance across a wide range of wood species and composite materials.
• Ultra sharp spur for accurate starting - the precision-ground center spur anchors the bit exactly on your mark before cutting begins, preventing the bit from wandering and ensuring hole placement accuracy every time.
• Steep angled cutting edges - produce holes that are smooth and flat, and create "chisel-like" curls for fast, clean chip removal, keeping the cutting zone clear to reduce friction, heat buildup, and premature dulling.
• Freud Limited Lifetime Guarantee - backed by Freud's lifetime coverage, giving you confidence in the long-term value of your investment.

Why This Product

• Conventional Forstner bit designs generate fine chips and dust that pack into the cutting area, building up heat and friction that dulls the bit prematurely and leaves ragged hole edges requiring sanding. The Precision Shear design ejects "chisel-like" curls efficiently, keeping the bit cooler and sharper through extended use.
• The serrated double-ground edge slices rather than scrapes throughout the full 360 deg. rotation, making this bit well suited for demanding materials like veneered plywood and solid surface where tearout and chipping can ruin a workpiece.
• At 13/16" diameter with a 3/8" shank and 3 1/2" overall length, this bit fits standard drill press chucks and handheld drills, giving you versatility across jobsite and shop environments without requiring specialty tooling.
• Austrian-forged construction combined with Freud's Limited Lifetime Guarantee sets this bit apart from entry-level options, making it a cost-effective long-term choice for professionals and serious hobbyists who bore flat-bottom holes regularly.

Specifications

• Brand: Freud
• Sub-Brand: Precision Shear
• Manufacturer Part Number: PB-0055
• Category: Forstner Bits
• Diameter: 13/16"
• Length: 3 1/2"
• Shank: 3/8"
• Rotation: RH
• Compatible Tools: Drill Press; Hand Held Drill
• Compatible Materials: Composites; Solid Surface; Veneered Plywood; Hardwoods; Softwoods
• Pack Quantity: 1
• Country of Origin: Austria

Approved Applications

• Drilling flat bottom holes in plywoods, hardwoods, and softwoods
• Pocket hole drilling in hardwoods, softwoods, and engineered wood products
• Overlapping hole drilling in composites, solid surface, and veneered plywood

Frequently Asked Questions

What makes the Precision Shear Forstner Bit different from a standard Forstner bit?

The Precision Shear design uses a double-ground, razor-sharp serrated edge that slices throughout the full rotation of the bit. This produces greater shearing action, faster chip ejection in "chisel-like" curls, and flawless flat-bottom holes with less splintering and chipping than conventional Forstner bit designs, which tend to produce fine dust and chips that collect in the cutting area and cause heat buildup and premature dulling.

What shank size does the PB-0055 use, and what tools are compatible?

The PB-0055 has a 3/8" shank and is compatible with both a drill press and a handheld drill. Make sure your drill or drill press chuck can accept a 3/8" shank before use.

What materials can this 13/16" Forstner bit cut through?

This bit is designed for use in composites, solid surface, veneered plywood, hardwoods, and softwoods. The serrated Precision Shear edge is especially effective in veneered plywood and hardwoods where clean entry and exit holes are critical to avoid tearout.

Does this Forstner bit come with any warranty?

Yes. The Freud Precision Shear Forstner Bit is backed by Freud's Limited Lifetime Guarantee, providing long-term assurance of quality and performance.
