The Freud 5/32" (Dia.) Through Hole Bit is an industrial-grade carbide tipped boring bit engineered for precision drilling on multiple spindle machines. Built to handle a wide range of wood-based and composite materials - from veneered plywood and hardwoods to softwoods and solid surface panels - this bit delivers accurate hole location thanks to its 60 deg. point geometry. Whether you are working on an automatic multi-spindle boring machine or a manual setup, the right-hand rotation design and 10mm shank with an adjustable top screw make this bit compatible with most boring machines, reducing setup time and improving workflow efficiency.

Key Features

• Industrial carbide tips - provide superior hardness and edge retention for maximum cutting life across demanding production environments
• 60 deg. point angle - ensures accurate hole location for through holes, reducing tearout and improving placement precision
• 10mm shank with adjustable top screw - allows compatibility with most boring machines, making setup fast and straightforward
• Right-hand (RH) rotation - matches the standard spindle direction of most drill presses and multi-spindle boring machines for reliable, consistent results
• 5/32" diameter with 70mm length and 35mm maximum hole depth - sized for through-hole drilling in furniture, cabinetry, and woodworking panel applications
• Freud Limited Lifetime Guarantee - backs the bit against defects, giving buyers long-term confidence in their investment
• Made in Italy - reflects Freud's precision European manufacturing standards for professional-grade tooling

Why This Product

• If you need a boring bit that fits most machines without modification, the 10mm shank with adjustable top screw delivers out-of-the-box compatibility across a wide range of automatic and manual multi-spindle boring equipment
• The 60 deg. point geometry is purpose-built for through holes, giving woodworkers and shop operators confident, on-target drilling with minimal drift in materials like veneered plywood, composites, and hardwoods
• Industrial carbide tips extend the working life of the bit well beyond standard steel alternatives, making this bit a cost-effective choice for high-volume production shops drilling softwoods, hardwoods, and solid surface materials
• Freud's Limited Lifetime Guarantee means this is a long-term shop tool, not a consumable - backed by the brand's commitment to performance and durability

Specifications

• Brand: Freud
• Manufacturer Part Number: TH39670R
• Category: Boring Bits - Through Hole Bits
• Diameter: 5/32"
• Length: 70mm
• Shank: 10mm
• Angle: 60 deg.
• Maximum Hole Depth: 35mm
• Rotation: RH
• Compatible Tools: Drill Press; Hand Held Drill
• Compatible Materials: Composites; Solid Surface; Veneered Plywood; Hardwoods; Softwoods
• Pack Quantity: 1
• Country of Origin: Italy

Approved Applications

• Drills all composition materials, solid surface materials, plywoods, hardwoods, and softwoods on automatic and manual multi-spindle boring machines

Frequently Asked Questions

What machines is the Freud TH39670R Through Hole Bit compatible with?

This bit is designed for multiple spindle machines, including both automatic and manual multi-spindle boring machines. The 10mm shank with an adjustable top screw makes it compatible with most boring machines, and it can also be used with drill presses and hand held drills.

What materials can this 5/32" through hole bit drill?

The Freud TH39670R is suitable for drilling composites, solid surface materials, veneered plywood, hardwoods, and softwoods - making it a versatile choice for furniture manufacturing, cabinetry, and general woodworking panel work.

What is the maximum hole depth for this bit?

The maximum hole depth for the Freud TH39670R is 35mm. The bit has an overall length of 70mm and a 5/32" diameter, with a 60 deg. point angle designed specifically for accurate through hole drilling.

Does this bit come with a guarantee?

Yes. The Freud TH39670R is backed by Freud's Limited Lifetime Guarantee, providing assurance of the bit's quality and long-term performance in professional boring applications.
