Product Features
Product Description
Simpson Strong-Tie ABA66RZ ABA ZMAX Galvanized Adjustable Standoff Post Base for Rough 6x6 Lumber is engineered by Simpson Strong-Tie to securely attach wooden posts to existing concrete foundations. Featuring a built-in 1-inch standoff that helps prevent rot at the post end and a slotted anchor hole for easy adjustability, this post base delivers a cost-effective, code-compliant solution for structural post installations in basements, exterior environments, and areas exposed to weather or water splash.
Key Features
- The slot in the base enables flexibility around the anchor bolt, making precise post placement easier
- The 1-in. standoff design meets code requirements for structural posts installed in basements or exposed to weather or water splash
- Increased uplift loads for earthquake or wind loading
- Nominal post size: Rough 6x6
- Made from 14-gauge steel
- ZMAX galvanization offers extra corrosion resistance for exterior and treated-wood applications
Specifications
- Model Number: ABA66RZ
- Member Size: 6x6 rough
- Gauge: 14
- Width: 6 in.
- Height: 2-7/8 in.
- Length: 5-3/16 in.
- Coating/Finish: ZMAX
- Standoff: 1 in.
- Installation Fasteners: Install with 16d common nails or #10 x 1-1/2 Strong-Drive SD screws (sold separately)
- Required Fasteners: (1) 5/8 in. concrete anchor and (8) 0.162 in. x 3-1/2 in. nails
- Country of Origin: United States
Frequently Asked Questions
- What size lumber is the ABA66RZ designed to fit?
- The ABA66RZ is designed exclusively for use with rough cut 6x6 lumber. It is part of the "R" series of post bases, which are intended specifically for rough cut lumber rather than standard dimensional lumber.
- What fasteners are required to install the ABA66RZ?
- The ABA66RZ can be installed with 16d common nails or #10 x 1-1/2 Strong-Drive SD connector screws to attach the base to the post. Anchoring to concrete requires one 5/8 in. concrete anchor. When using nails, use (8) 0.162 in. x 3-1/2 in. nails as specified.
- Why does the ABA66RZ include a 1-inch standoff?
- The built-in 1-in. standoff elevates the bottom of the post off the concrete surface, helping to prevent moisture accumulation and rot at the post end. This standoff design also meets code requirements for structural posts installed in basements or in areas exposed to weather or water splash.
- What makes the ZMAX coating suitable for exterior and treated-wood applications?
- ZMAX galvanization provides a thicker zinc coating than standard galvanization, offering enhanced corrosion resistance. This makes the ABA66RZ well-suited for exterior installations and applications involving pressure-treated lumber, where exposure to moisture and corrosive preservatives is a concern.
Note: Product dimensions may differ from picture. See item description for specifications.
