The Simpson PC8Z ZMAX Galvanized Post Cap for 8x from Simpson is built for fast, reliable post-to-beam connections in structural framing applications. Designed for nominal 8x solid sawn and rough lumber posts, this post cap features in-line post and beam flanges so that a single model can accommodate several post sizes - giving contractors and builders a flexible solution without the need for multiple SKUs on the job site. The ZMAX galvanized finish delivers robust corrosion resistance suited for a wide range of exposure conditions, making it a dependable choice for both interior and exterior structural connections.

Key Features

• ZMAX galvanized finish is standard - provides enhanced corrosion resistance to meet exposure conditions in many environments, helping the connector hold up over time in demanding applications
• In-line post and beam flange design - allows one model to accommodate several post sizes, reducing the number of parts needed on the job and simplifying procurement
• Compatible with 0.148 in. x 3 in. nails or Strong-Drive SD Connector screws - supports fast, straightforward installation using commonly available fasteners or Simpson's own connector screws
• Made from 16-gauge steel - delivers structural strength appropriate for post-to-beam framing connections in solid sawn and rough lumber construction
• Designed for nominal 8x post-to-beam connections - purpose-built geometry ensures a secure, consistent fit for 8x lumber, reducing guesswork and rework during installation

Why This Product

• One connector, multiple post sizes - the in-line flange configuration means a single PC8Z can serve several post sizes, cutting down on inventory needs and keeping framing projects moving efficiently
• Built-in corrosion protection from the start - the ZMAX finish comes standard rather than as an upgrade, so the connector is ready for challenging exposure environments right out of the box
• Installer-friendly fastener options - compatibility with both nails and Strong-Drive SD Connector screws gives crews the flexibility to work with the tools and fasteners they already have on hand
• Trusted construction-grade materials - 16-gauge steel construction and suitability for both solid sawn and rough lumber post-to-beam connections make this cap a practical fit for a broad range of structural framing applications

Specifications

• Model Number: PC8Z
• Nominal Post Size: 8x
• Seat Width: 7-1/2 in.
• Gauge: 16
• Coating/Finish: ZMAX
• Installation Fasteners: Installs with 0.148 in. x 3 in. nails or the #9 x 1-1/2 in. Strong-Drive SD Connector screw (sold separately)
• Width: 7-1/2 in.
• Country of Origin: United States

Downloads and Resources

• View Specifications

Frequently Asked Questions

What post size is the PC8Z designed for?

The PC8Z is designed for a nominal 8x post size. Its in-line post and beam flange design allows a single model to accommodate several post sizes for added versatility.

What fasteners are required to install the PC8Z?

The PC8Z installs with 0.148 in. x 3 in. nails or the #9 x 1-1/2 in. Strong-Drive SD Connector screw.

What is the ZMAX finish and why does it matter?

The ZMAX finish is a hot-dip galvanized coating that is standard on the PC8Z to meet exposure conditions in many environments, providing enhanced corrosion resistance compared to standard galvanized finishes.

What type of lumber connections is the PC8Z suitable for?

The PC8Z is designed for use with 8x solid sawn and rough lumber post-to-beam connections, making it well-suited for a variety of structural framing applications.

Note: Product dimensions and/or screw holes may differ from picture. Please see item description for specifications.
